Highlights:
Supports the battery mode or non-battery mode.
Non-battery mode: charging with solar (Main) and utility (Assist) simultaneously.
Surge and reverse connection protections to support the lithium battery system perfectly.
Three charging modes: Solar only, Solar priority, Utility & Solar.
Two AC output modes: Utility priority and Inverter priority.
High tracking efficiency of MPPT no less than 99.5%.
PFC technology achieves a high power factor of AC to DC charging and reduces grid capacity usage. Advanced SPWM technology and pure sine wave output.
Customized charging current and discharging limited current.
SOC with the self-learning feature is visible on LCD.
4.2 inch LCD to monitor and modify system parameters.
Optional WiFi or GPRS Remote control by the RS485 isolated communication port.
Optional BMS-Link port, which takes the charging and discharging control from BMS.
Specification
|
Item
|
UP2000-HM6021
|
UP3000-HM10021
|
UP3000-HM5041
|
UP3000-HM8041
|
|
Rated battery voltage
|
24VDC
|
48VDC
|
|
Battery input voltage
|
21.6~32VDC
|
43.2~64VDC
|
|
Max. battery charging current
|
60A
|
100A
|
50A
|
80A
|
|
Inverter output
|
|
Continuous output power
|
2000W
|
3000W
|
3000W
|
3000W
|
|
Max. surge power(3S)
|
4000W
|
6000W
|
6000W
|
6000W
|
|
Output voltage range
|
110VAC(-3%~+3%), 120VAC(-10%~+3%)
|
|
Output frequency
|
50/60±0.2%
|
|
Output wave
|
Pure Sine Wave
|
|
Load power factor
|
0.2-1(Load power ≤ Continuous output power)
|
|
Distortion THD
|
THD≤5%(Resistive load)
|
|
80% rated output efficiency
|
89%
|
90%
|
91%
|
91%
|
|
Max. Rated output efficiency
|
88%
|
88%
|
90%
|
90%
|
|
Max. output efficiency
|
90%
|
92%
|
92%
|
92%
|
|
Switch time
|
10ms(Switch from the utility output to the inverter output), 15ms(Switch from the inverter output to the utility output)
|
|
Utility charging
|
|
Utility input voltage
|
88VAC~132VAC (Default), 80VAC~140VAC(Programmable)
|
|
Utility input frequency
|
40~65Hz
|
|
Max. utility charge current
|
60A
|
80A
|
40A
|
40A
|
|
Solar charging
|
|
Max. PV open circuit voltage
|
250V(At minimum operating environment temperature), 220V(At 25℃ environment temperature)
|
|
MPPT voltage range
|
60~200V
|
|
Max. PV input power
|
2000W
|
3000W
|
3000W
|
4000W
|
|
(Note: For the curve of Max. PV input power Vs. PV open-circuit voltage, see chapter 3.4 Operating mode for details.)
|
|
Max. PV charging power
|
1725W
|
2875W
|
2875W
|
4000W
|
|
Max. PV charging current
|
60A
|
100A
|
50A
|
80A
|
|
Equalize charging voltage
|
29.2V(AGM default)
|
58.4V(AGM default)
|
|
Boost charging voltage
|
28.8V(AGM default)
|
57.6V(AGM default)
|
|
Float charging voltage
|
27.6V(AGM default)
|
55.2V(AGM default)
|
|
Low voltage disconnect voltage
|
21.6V(AGM default)
|
43.2V(AGM default)
|
|
Tracking efficiency
|
≥99.5%
|
|
Temp. compensate coefficient
|
-3mV/℃/2V(Default)
|
|
General
|
|
Surge current
|
50A
|
60A
|
56A
|
95A
|
|
Zero load consumption
|
<1.6A
|
<1.6A
|
<1.2A
|
<0.8A
|
|
(without PV and utility connection, turn on the load output)
|
|
Standby current
|
<1.2A
|
<1.0A
|
<0.7A
|
<0.6A
|
|
(without PV and utility connection, turn off the load output)
|
|
Mechanical Parameters
|
|
Dimension(H x W x D)
|
607.5x381.6x127mm
|
642.5x381.6x149mm
|
642.5x381.6x149mm
|
642.5x381.6x149mm
|
|
Mounting size
|
585*300mm
|
620*300mm
|
620*300mm
|
620*300mm
|
|
Mounting hole size
|
Φ10mm
|
Φ10mm
|
Φ10mm
|
Φ10mm
|
|
Net Weight
|
15kg
|
19kg
|
19kg
|
19kg
|
|
Enclosure
|
IP30
|
|
Relative humidity
|
< 95% (N.C.)
|
|
Environment temperature
|
-20℃~50℃
|
Solutions
We provide a complete solutions including site survey, propose professional plan according to customer’s request ,technical support, and maintenance service for Telecommunication Companies in and out of China. We have a competent team and a network of trusted Partners around the world.
FAQ :
1. How do you control the quality?
A:All products before the shipment are simulated usage scenarios, load and full load and current sharing test to ensure the quality of the product.
2. What is your minimum order quantity?
A:There is no minimum order quantity, and one can also be done. The only difference is the price and schedule.
3. Can you introduce your company?
A:I am very honored. I will send you the company’s introduction document later to give you a more comprehensive and direct introduction to our company’s information.
4. What are the advantages of your company?
A:Adequate inventory, and supply guarantee for the subsequent renewal of supply, flexible provided according to different to different needs of customers, providing different solutions.
5. Can i send samples?Report it to me along with the price?
A:You can send samples, the samples are subject to large pride, and the freight needs to be borne by you.
6. How do your company deal with the problem on quality?
A:Our company has been doing this industry for almost 10 years. It has already had a certain reputation. We will carefully analyze it. If it is indeed our quality problem, you can rest assured that it will do things according to the contract agreement and will never let you have any after the worries, our service team will be happy to serve you.
7 What about the quality ?
A:100% original with new package. we will test each item before posted to make sure each item with good quality.
8 How many months for guarantee ?
A: 1 year quality guarantee
9 How to deal with any inferior -quality goods ?
A: Goods can be post by with our charge of post fee for any bad quality products within guarantee time.
